Specifications:
Minimal Media Thickness:
Max. 10 mm, 0.39
Patch Size:
Min: 6 mm x 7 mm (Width x Height)
Scanning Speed:
> 400 patches / Minute, IT8.7/3 chart (924 patches) <= 2.2 minutes (with scanning mode in M0 measurement condition)
Unit Color:
Silver/Black
Dimensions (length, width, height):
510 x 460 x 170 mm, 20 x 18.1 x 6.7 (Width x Depth x Height)
Weight:
4.5 kg, 9.9 lb (without i1 Pro device)
Communication Interface:
USB 1.1
Experience Level:
Intermediate to Advance
Software Development Kit:
Available for OEM customers
Voltage:
100 to 240 VAC, 50 / 60 Hz
Scanning Area:
Positioning Area: 32 x 23 cm, 12.6” x 9” (Width x Height)
Calibration:
Automatic on Integrated Calibration Reference
Measurement Background:
white
Warranty:
Twelve (12) months from the date of sale, unless different local regulations apply. Product registration is required to receive X-Rite technical support during the warranty period. Registration can occur directly through the software, on our website, or via phone. Users are encouraged to register their product within the first 30 days of use.
What's Included?:
i1iO table; Replacement Glider Ring; Auto rating power supply 100 – 240 VAC, 50/60Hz; Main power cable; USB cable; i1 Applications DVD; Quick Start Guide
Connectivity:
Powered USB port
